HPC 1300

High-strength sheet moulding compound for load-bearing structural applications.

Product Overview

Menzolit® HPC 1300 is a special SMC for high-strength applications. It is a glass fibre reinforced sheet moulding compound based on unsaturated polyester resin, combining chopped, random, and continuous unidirectional glass fibres for exceptional strength and stiffness along fibre orientation. The compound is fire-retardant, non-melting, and produces minimal smoke in case of fire.

Application Industries

Commercial Vehicle

Industrial

Automotive

Key Properties

Very high strength and stiffness along fibre orientation.
Unique combination of chopped and continuous unidirectional glass fibres.
Fire-retardant with no halogens, heavy metals, or REACH SVHC candidates.
Anisotropic properties require careful design and moulding consideration.

Compliance & Certifications

UL 94 certified for flammability
Glow Wire Index tested
IEC 60093 surface resistivity standards
REACH SVHC compliant

Talk to Our HPC Expert

HPC 1300 is a special SMC engineered for demanding load-bearing structural applications. Its unidirectional and chopped fibre reinforcement provides exceptional stiffness and strength along fibre orientation. Fire safety is enhanced with low smoke emission and no droplet formation. Designers and moulders must account for anisotropic flow behaviour to achieve optimal part performance.

HPC 1300 meets the high mechanical and fire safety requirements of automotive, commercial vehicle, and industrial sectors. Its unidirectional reinforcement ensures superior load-bearing performance. Compliance with UL 94 and Glow Wire standards guarantees fire safety. Additionally, dimensional stability and controlled flow allow for precise, high-performance parts that meet stringent industry regulations.

Menzolit® HPC 1300 offers an excellent balance of high-strength performance, mouldability, and thermal stability. The combination of chopped and unidirectional fibres ensures strength and stiffness in fibre orientation, while continuous service temperature reaches 170°C. It exhibits high flexural and tensile loads while maintaining low water absorption, providing durable, reliable components.

Density: 1.7 g/cm³

Flexural Strength: 95–740 MPa

Tensile Strength: 70–410 MPa

HDT: >200 °C

Flammability: UL 94

* The technical parameters are average values. Depending on the formulation and customer requirements, different technical values may be achieved.

Download HPC 1300 Datasheet

HPC 1300 is compression moulded in heated steel moulds, with chrome-plated tools recommended for use. The material’s anisotropic flow requires careful design consideration during part development. Supplied on rolls with styrene barrier film, it includes specific handling and storage instructions. Technical support is available for processing, moulding, testing, and troubleshooting to ensure optimal performance in high-strength applications.
