Products Detailed (HPC 1200)

HPC 1200

High-strength sheet moulding compound for load-bearing structural applications.

Product Overview

Menzolit® HPC 1200 is a specially formulated sheet moulding compound (SMC) combining chopped, random, and continuous unidirectional glass fibres. It delivers exceptional strength and stiffness along the fibre orientation while maintaining good mouldability. The compound is fire-retardant, non-melting, and produces minimal smoke in case of fire.

Application Industries

Automotive

Commercial Vehicle

Industrial

Key Properties

High strength and stiffness along fibre orientation for structural components.
Unique combination of chopped and continuous glass fibres for unidirectional reinforcement.
Fire-retardant with no halogens, heavy metals, or REACH SVHC candidates.
Anisotropic properties require design and moulding considerations for optimal performance.

Compliance & Certifications

UL 94 certified for flammability
Glow Wire Index tested
IEC 60093 surface resistivity standards
REACH SVHC compliant

Talk to Our HPC Expert

HPC 1200 is engineered for high-strength, load-bearing structural applications. Its combination of chopped and unidirectional fibres provides superior stiffness and strength along fibre orientation. Fire safety is enhanced with low smoke emission and no droplet formation. Design and moulding must account for anisotropic flow behaviour, ensuring reliable part performance in demanding applications.

HPC 1200 is ideal for industries that demand mechanical strength, fire safety, and precise thermal performance. Its anisotropic reinforcement ensures superior load-bearing capacity in automotive, commercial vehicle, and industrial applications. Compliance with UL 94 and Glow Wire standards ensures fire safety. The material’s controlled flow and dimensional stability enable precise, high-performance parts that meet industry regulations and design requirements.

Menzolit® HPC 1200 delivers a balance of mouldability, high mechanical performance, and thermal stability. Its combination of chopped and unidirectional glass fibres ensures strength and stiffness along the orientation direction while maintaining processable flow characteristics. Continuous service temperature reaches 170°C, and the material withstands high flexural and tensile loads.

Density: 1.8 g/cm³

Flexural Strength: 95–650 MPa

Tensile Strength: 40–300 MPa

HDT: >200 °C

Flammability: UL 94

* The technical parameters are average values. Depending on the formulation and customer requirements, different technical values may be achieved.

Download HPC 1200 Datasheet

HPC 1200 is compression moulded in heated steel moulds, with chrome-plated tools recommended for use. Designers must consider the material’s anisotropic flow and fibre orientation during part design. Supplied on rolls with styrene barrier film, the material has specific handling and storage guidelines. Technical support is available for processing, moulding, testing, and troubleshooting, ensuring optimal application performance.
