Products Detailed (SMC 2600)

SMC 2600

Sheet moulding compound with antistatic properties for high-voltage and explosive environments.

Product Overview

Menzolit® SMC 2600 is a sheet moulding compound based on unsaturated polyester resin, reinforced with glass fibre and mineral fillers. It offers controlled conductivity to provide antistatic performance, making it ideal for explosion-proof components. The product maintains structural integrity under heat and fire exposure, without melting or forming droplets.

Application Industries

Electrical

Energy

Key Properties

Antistatic performance for electrical safety in explosive environments
High mechanical strength and stiffness
Excellent thermal resistance up to 165°C continuous service
Fire retardant with low smoke generation

Compliance & Certifications

UL Yellow Card certified
UL 94 V-0 fire rating
UL 746 C dielectric insulation compliance
Free from halogens, heavy metals, and REACH SVHC candidates

Talk to Our SMC Expert

SMC 2600 combines high strength, thermal stability, and antistatic performance for safe use in explosive atmospheres. It is suitable for compression moulding in heated steel tools and retains its structural integrity in challenging industrial environments. Its controlled surface resistivity ensures protection for sensitive electrical components. Technical support is available for optimising moulding and design.

This product is ideal for electrical, energy, and chemical industries where safety is critical. Its antistatic properties reduce the risk of sparks, while high mechanical and thermal performance meet industrial standards. Compliance with UL 94 V-0 and UL 746 C ensures suitability for high-risk, high-temperature environments. SMC 2600 offers a reliable solution for components exposed to harsh chemical, mechanical, and electrical conditions.

SMC 2600 provides a unique combination of antistatic and mechanical performance for industrial and electrical applications. It can withstand compression moulding at elevated temperatures while maintaining dimensional stability and strength. Fire-retardant properties and low smoke generation make it suitable for regulated environments. Surface resistivity and dielectric performance are optimised for explosion-proof design.

Density: 1.8 g/cm³ (ISO 1183)

Flexural Strength: 180 MPa (EN ISO 14125)

Tensile Strength: 75 MPa (EN ISO 527-4)

HDT: >200°C (EN ISO 75-2)

Flammability: UL 94 V-0 @3.2 mm

* The technical parameters are average values. Depending on the formulation and customer requirements, different technical values may be achieved.

Download SMC 2600 Datasheet

Menzolit® SMC 2600 is processed via compression moulding using heated steel moulds and chrome-plated tools for optimal surface quality. Handling should follow standard safety procedures, with rolls stored in dry conditions. Technical guidance is available for moulding parameters, design optimisation, and testing for specific applications. FAQs and troubleshooting support are provided to ensure peak performance and safety compliance.
