Products Detailed (BMC 0390)

BMC 0390

Low-profile BMC with minimal shrinkage, ideal for functional components in light colours.

Product Overview

Menzolit® BMC 0390 is a bulk moulding compound based on unsaturated polyester resin. The product is glass fibre reinforced and contains mineral fillers for strength and dimensional stability. It offers minimal fire retardancy, does not melt or form droplets, and has low smoke generation.

Application Industries

Electrical

Energy

Industrial

Sanitary

Key Properties

Low shrinkage, approximately zero
Glass fibre reinforced for mechanical strength
Minimal fire retardancy UL 94 HB (higher on request)
Suitable for light-coloured functional components

Compliance & Certifications

Halogen-free
Free from REACH SVHC candidates
UL 94 HB fire rating
Glow wire 750°C

Talk to Our BMC Expert

BMC 0390 provides excellent dimensional stability due to its low shrinkage formulation. It allows consistent colour and surface finish for light-coloured parts. The material is injection moulded in heated steel moulds, ensuring precision and repeatability. It is safe to handle, halogen-free and suitable for electrical, energy, industrial and sanitary applications.

The product meets industry requirements for low-profile, dimensionally stable components. Its minimal shrinkage ensures tight tolerances in electrical and industrial applications. UL 94 HB and glow wire 750°C ratings align with electrical safety standards. Glass fibre reinforcement provides the mechanical strength required in sanitary and energy applications.

BMC 0390 is designed for precise, high-quality injection moulding with low shrinkage and consistent surface finish. It maintains performance under continuous service up to 165°C and heat distortion above 200°C. Mechanical and electrical properties make it suitable for multi-industry use. Available in all colours with standard packaging and optional customised solutions.

Density: 1.9 g/cm³ (ISO 1183)

Flexural Strength: 120 MPa (EN ISO 14125)

Tensile Strength: 35 MPa (EN ISO 527-4)

HDT: >200°C (EN ISO 75-2)

Flammability: UL 94 HB@3 mm

* The technical parameters are average values. Depending on the formulation and customer requirements, different technical values may be achieved.

Download BMC 0390 Datasheet

Processing guidance includes injection moulding in heated steel moulds with chrome-plated tools for optimal performance. Material handling and storage in styrene-tight bags ensures shelf life and safety. Technical support is available for datasheets, consultations and testing. Design and troubleshooting tips are provided to achieve low-shrink, light-colour components consistently.
