BMC 0190

High-performance BMC solution for electrical and industrial components demanding fire safety and high mechanical strength.

Product Overview

Menzolit® BMC 0190 is a glass fibre-reinforced bulk moulding compound based on unsaturated polyester resin. It offers a strong balance of mechanical performance, heat resistance and flame retardancy. The compound is halogen-free and free from REACH SVHC candidates, making it a dependable choice for sustainable and safe applications.

Application Industries

Electrical

Energy

Industrial

Key Properties

UL 94 V-0 fire retardancy at 3 mm
Glow wire resistance up to 960°C
Excellent mechanical and electrical strength
Low shrinkage and high dimensional stability

Compliance & Certifications

UL 94 V-0 Certified
Glow Wire Test (IEC 60695) up to 960°C
REACH and RoHS Compliant
Halogen-free formulation

Talk to Our BMC Expert

BMC 0190 delivers high electrical insulation, heat resistance and flame safety while maintaining superior mechanical strength. Its formulation provides consistent moulding results, stable performance under thermal stress, and reliability for components in demanding environments. The material’s halogen-free composition aligns with sustainability and compliance goals.

For the electrical and energy sectors, BMC 0190 meets rigorous safety and performance standards, including UL 94 V-0 and glow wire resistance up to 960°C. It supports long-term thermal stability and dimensional accuracy in electrical switchgear, connectors, and insulation parts, ensuring compliance with industry reliability and safety benchmarks.

BMC 0190 provides a balanced mix of thermal, mechanical and electrical performance for advanced moulding applications. It maintains form under continuous use at 165°C and exceeds 200°C in heat distortion resistance.

Density: 1.8 g/cm³

Flexural Strength: 100 MPa

Tensile Strength: 30 MPa

HDT: >200°C

Flammability: UL 94 V-0 @ 3 mm

* The technical parameters are average values. Depending on the formulation and customer requirements, different technical values may be achieved.

Download BMC 0190 Datasheet

Menzolit® BMC 0190 can be injection moulded in heated steel moulds, ideally using chrome-plated tools for longevity. Processing involves controlled temperature and pressure for optimal surface finish and part integrity. Store in styrene-tight packaging to preserve quality. Technical support includes moulding consultations, testing guidance, and design assistance for improved application performance.
