Products Detailed (BMC 0170)

BMC 0170

Reliable high-strength bulk moulding compound for electrical and industrial applications.

Product Overview

Menzolit® BMC 0170 is a bulk moulding compound based on unsaturated polyester resin, reinforced with glass fibre and mineral fillers. It offers high strength while maintaining excellent fire retardancy and low smoke emission. Suitable for injection moulding in heated steel moulds, it is recommended to use chrome-plated tools.

Application Industries

Electrical

Energy

Industrial

Key Properties

High mechanical strength for structural components
Fire retardancy: UL 94 HB, Glow Wire 750°C
Halogen-free and free from REACH SVHC candidates
Excellent electrical insulation and dimensional stability

Compliance & Certifications

UL 94 HB
Glow Wire 750°C
REACH compliant (no SVHC candidates)
Halogen-free

Talk to Our BMC Expert

Menzolit® BMC 0170 combines high mechanical strength with excellent fire resistance, making it ideal for electrical and industrial applications. The material is halogen-free, does not form droplets in fire, and generates minimal smoke. The optimised formulation ensures easy processing and reliable performance in demanding environments.

BMC 0170 meets critical requirements for electrical, energy, and industrial sectors. Its UL 94 HB rating and Glow Wire 750°C certification ensure safety in electrical components. High strength and stiffness provide durability in mechanical applications, while halogen-free composition and compliance with REACH SVHC standards meet regulatory requirements.

Menzolit® BMC 0170 offers predictable performance under mechanical, thermal and electrical stresses. It is designed for injection moulding processes with stable dimensional properties and low water absorption, making it suitable for precision electrical components and industrial parts.

Density: 1.9 g/cm³ (ISO 1183)

Flexural Strength: 120 MPa (EN ISO 14125)

Tensile Strength: 35 MPa (EN ISO 527-4)

HDT: >200°C (EN ISO 75-2)

Flammability: UL 94 HB, Glow Wire 750°C

* The technical parameters are average values. Depending on the formulation and customer requirements, different technical values may be achieved.

Download BMC 0170 Datasheet

Menzolit® BMC 0170 is processed via injection moulding in heated steel moulds, preferably using chrome-plated tools. Store in a dry environment to maintain shelf life. Technical support is available for processing guidance, testing, and troubleshooting. Design recommendations are provided to achieve optimal mechanical and electrical performance.
