Products Detailed (BMC 0160)

BMC 0160

Standard BMC solution for electrical and industrial components demanding fire safety and mechanical strength.

Product Overview

Menzolit® BMC 0160 is a glass fibre-reinforced bulk moulding compound based on unsaturated polyester resin. It offers a strong balance of mechanical performance, heat resistance and flame retardancy. The compound is halogen-free and free from REACH SVHC candidates, making it a dependable choice for sustainable and safe applications.

Application Industries

Electrical

Energy

Industrial

Key Properties

UL 94 HB
Glow wire resistance up to 750°C
Good mechanical and electrical strength
Low shrinkage and high dimensional stability

Compliance & Certifications

UL 94 HB
Glow Wire Test (IEC 60695) up to 750°C
REACH and RoHS Compliant
Halogen-free formulation

Talk to Our BMC Expert

BMC 0160 delivers good electrical insulation, heat resistance and flame safety while maintaining good mechanical strength. Its formulation provides consistent moulding results, stable performance under thermal stress and reliability for components in demanding environments. The material’s halogen-free composition aligns with sustainability and compliance goals.

BMC 0160 provides a balanced mix of thermal, mechanical, and electrical performance for standard moulding applications. It maintains form under continuous use at 165°C and exceeds 200°C in heat distortion resistance.

Density: 1.8 g/cm³ (ISO 1183)

Flexural Strength: 80 MPa (EN ISO 14125)

Tensile Strength: 30 MPa (EN ISO 527-4)

HDT: >200°C (EN ISO 75-2)

Flammability: UL 94 HB

* The technical parameters are average values. Depending on the formulation and customer requirements, different technical values may be achieved.

Download BMC 0160 Datasheet

Menzolit® BMC 0160 can be injection moulded in heated steel moulds, ideally using chrome-plated tools for longevity. Processing involves controlled temperature and pressure for optimal surface finish and part integrity. Store in styrene-tight packaging to preserve quality. Technical support includes moulding consultations, testing guidance, and design assistance for improved application performance.
